Product Overview
RFID Bolt Seal is a high security intelligent cargo sealing solution. It combines the ISO 17712 certified security of a mechanical bolt seal with advanced UHF RFID technology. It is embedded with RFID chip for electronic identification and automatic data collection, designed specifically for modern smart logistics and supply chain supervision, with robust physical anti-tampering performance and full digital traceability.
This seal replaces error-prone manual logging with digital identification, drastically cuts human error, speeds up port cargo clearance efficiency and greatly improves end-to-end supply chain visibility. It is the optimal security choice with high-standard management of shipping containers and trailers.
Key Features
High-Security Steel Bolt Construction
Manufactured from hardened steel to resist cutting, tampering, and unauthorized removal.
01
Integrated RFID Technology
Embedded RFID chip enables fast, contactless identification and data collection.
02
Tamper-Evident Locking Mechanism
Provides clear visual evidence if the seal has been compromised.
03
Long-Range RFID Reading Capability
Allows rapid identification without direct visual inspection.
04
Custom Data Encoding
RFID chips can be programmed according to project-specific requirements.
05
Customization & OEM
Custom RFID Encoding
Custom chip encoding and encryption enable plug-and-play sync with WMS and ERP systems.
Global Frequency Selection
Compatible with LF, HF and universal UHF frequency configurations for complete scanning compatibility with worldwide port facilities.
Laser Marking & Branding
The company logos are permanently laser etched and cannot be changed, providing tamper evidence and anti-counterfeiting protection.
Bulk Color Customization
Available in any UV-resistant color for mass production, enabling fast cargo classification and inventory sorting at ports.
Product Details
Specifications
Pin diameter 8mm
Molded pin measures 75mm*21mm*8mm
Molded chamber 28mm*23mm
Locking body-Copperized plated steel
Printing
Laser printing for black color and name, logo, sequential numbers & barcode.
Hot stamping print available for all colors.
Applications
Ocean Freight & Container Shipping
Ports & Terminal Operations
Rail Transportation
Trucking & Logistics
Packing
10 sets per pack; 250 sets per carton
Carton dimensions: 50cm * 40cm * 13cm
Carton Weight: 20kg
FAQ
Q1: Are your RFID bolt seals fully compliant with ISO 17712:2013 and C-TPAT?
A: Yes. Our RFID bolt seals feature a heavy-duty hardened steel lock that is fully certified as an H-Class (High Security) seal under ISO 17712:2013. They satisfy all physical strength requirements for C-TPAT, PIP, and AEO global customs security frameworks while adding a digital layer of protection.
Q2: What RFID chips do you use, and can they integrate with our existing WMS/ERP system?
A: We utilize premium, globally standard RFID chips (available in UHF, HF, or LF bands, compliant with EPC Class 1 Gen 2 / ISO 18000-6C protocols). We provide open API data structure support and custom chip programming/encryption so the seals can sync seamlessly with your current warehouse and logistics tracking software.
Q3: What happens if the RFID tag is physically destroyed or the port lacks a reader?
A: We design every seal with physical scanning redundancy. The unique serialized number, Barcode 128, or QR code is permanently laser-etched onto the seal body and synchronized with the embedded chip data, allowing operators to execute traditional optical scans or manual verifications instantly.
Q4: What is the maximum read range for your UHF RFID container seals?
A: Depending on the scanning hardware, port infrastructure, and environment, our UHF RFID bolt seals offer a reliable read range of up to 5 to 8 meters (16 to 26 feet). This enables automated, high-speed gate-in/gate-out reading without forcing truck drivers to exit their vehicles.
Our high security seals are available in a variety of customization options.
They are made of alloy steel by precision machining, safe, reliable and easy to operate, with excellent durability and wide resistance to high/low temperatures without easy aging.
The seals are made from a high tensile alloy material and offer high resistance to shear and tension.
Our structural design fuses sophisticated anti-tampering construction with user-friendly operation: the structure is invulnerable to damage from unauthorized individuals and enables rapid and precise handling by authorized staff.
Every seal is assigned a special serial number and anti-counterfeiting mark. They are made with high-quality materials and sophisticated locking systems, which prevent non-authorized opening or sabotage, providing a strong technical guarantee for the safe control of cargo.
